Roca, Wiper motor W12, 38mm shaft / 12V, IP65, 2 speeds

Description

Roca W12 wiper motor is a 12V waterproof wiper motor, ideal for boats with metal chassis. It has stepless adjustment of the wipe angle from 45˚ to 110˚ and offers two speeds for optimal operation. The design ensures easy angle adjustment after installation.

• Brand: Roca
• Weight: 1.84 kg
• Shaft length: 38 mm
• Shaft Ø: 13.8 mm
• IP rating: IP65
• Material: Aluminium
• Max hull thickness: 16 mm
• Volt: 12 V
• Package dimensions: Dimensions: 14 cm × 11 cm × 20 cm | Gross weight: 1.84 kg

Roca's wiper motor has an insulated chassis, so it can also be used in metal boats. Stepless adjustment of the wipe angle from 45˚ to 110˚ for maximum visibility makes it easy to adapt to your needs and very popular among boat owners. The angle can easily be changed after installation. Adjustable self-parking in the right or left position/side. The wiper shaft is made of Ø13.8 mm stainless steel.

2 speeds; slow: 35 strokes/minute, fast: 55 strokes/minute. 100% waterproof, compact housing, made of aluminium. Max length arm/blade combination 610 mm x 560 mm.

Approvals: CE approved: EN55 014 - EMC directive 89/336/EEC. EN60335-1: 94. The product has CE marking in accordance with the low voltage directive 72/23/EEC.
