Rutgerson, RAW turtle block 60 mm horizontal plate

Description

This turtle block with a horizontally curved plate is used for line handling on areas of the boat where the surface has a horizontal curve. It is relevant when you want to lead halyards, trim lines or control lines close along the mast or other curved surfaces without the block lifting.

• Brand: Rutgerson
• Working load: 800 kg
• Breaking load: 1600 kg
• Sheave diameter: 60 mm
• Rope Ø: 6-14 mm
• Product weight: 239 g
• Product dimensions: 50/21 mm × 110 mm
• Package dimensions: Dimensions: 3 cm × 7 cm × 14 cm | Gross weight: 0.27 kg

This turtle block with a horizontally curved plate is used for line handling on areas of the boat where the surface has a horizontal curve. It is relevant when you want to lead halyards, trim lines or control lines close along the mast or other curved surfaces without the block lifting. It provides a fixed turning point and stable line handling under sail. The block uses a plain bearing, which provides smooth rotation and low friction under load. The sides and sheave are made of composite, which gives low weight and good durability. The horizontal stainless steel plate is shaped with a curved profile that matches the natural shape of the mast or other surfaces, providing a stable installation and reducing twist. The turtle block functions as a fixed block in the rig's line handling. It is typically used at the mast base, where it can act as a turning block when lines need to be led aft. The curved plate fits surfaces with a profile radius of approx. 190–400 mm and is suitable as a solution when standard mast base blocks sit too low or do not follow the surface correctly. This block is practical on boats where space is limited and where you want stable and tidy line handling. It can be mounted on both masts and other lightly curved surfaces and can be used in both cruising and racing setups. The working load varies by model and covers common needs in line routing systems.

INSTRUCTIONS FOR USE Preparation: Clean the mounting surface of dirt and salt.

Mounting: 1 Position the block so the plate follows the curve of the surface. 2 Mark and drill pilot holes if necessary. 3 Fasten with suitable stainless steel screws.

After use: Rinse the block in fresh water and check that the sheave rotates freely.
